AIMS Power 3000 Watt Pure Sine Low Frequency Inverter with built-in battery charger and transfer switch. This inverter charger is perfect for small-sized industrial applications that depend upon power being available even under heavy load. This heavy-duty inverter charger is ready to go wherever you need it. Use this product for renewable solar, off-grid home and business back up power, mobile and emergency backup power applications anywhere that uses 110 or 120 volts of alternating current. This product also has auto frequency detection that allows users to operate at either 50 or 60 hertz.Use this product to power your essential household appliances during a power outage emergency.
See Features Below:
Listed to UL 458 Standards and CSA 22.2 No 107.1
3000 watt low frequency inverter
9000 watt surge for 20 seconds -3x surge capability
Battery priority selector
AC direct connect terminal block
GFCI - 20 amps
Marine coated and protected
Multi stage smart charger 100 Amp GEL, AGM, Lead and lithium LiFePO4
Remote panel available
Auto gen start
Auto frequency
10msec typical transfer time
7 battery type settings for charger
Selectable 25W power save mode (hibernation)
Automatic transfer switch
This inverter is also great in a smaller RV or boat. If 3000 watts is not enough power, check out our full line of low frequency inverter chargers available in 12, 24 & 48 volt versions. This AIMS power inverter charger is capable of accepting any source of 120v AC power to charge batteries, including a gas or diesel generator or shore power at an RV park/truck stop. It will even accept power from an extension cord plugged into your wall outlet at home.
Inverter Output Specifications | |
---|---|
Listed to UL 458 Standards | |
Continuous Output Power | 3000 Watts |
Surge Rating | 9000 Watts (20 Seconds) |
Output Waveform | Pure Sine/Same as input (Bypass Mode) |
Output Voltage | 100-110-120Vac |
Nominal Efficiency | >92% (Peak) |
Line Mode Efficiency | >95% |
Output Frequency | 50Hz +/- 0.3Hz / 60Hz +/- 0.3Hz |
Bypass Terminal Breaker - 40 amps | |
Typical Transfer Time | 10ms (Max) |
THD | < 10% DC |
Ambient Operating Temperature | 14°F to 122°F (-10°C to 50°C) |
Input Specifications | |
Nominal Input Voltage | 12.0Vdc |
Minimum Start Voltage | 10.0Vdc |
Low Battery Alarm | 10.5Vdc-11.0Vdc |
Low Battery Trip | 10.0Vdc-10.5Vdc |
High Voltage Alarm | 16.0Vdc |
Low Battery Voltage Restart | 13.3Vdc |
Idle Consumption | 55 Watts |
Charger Breaker - 30 amps | |
Power Saver Mode Idle Consumption | 21.7 Watts |
Charger Specifications | |
Output voltage | Depends on battery Type |
Charger Rate | 100A |
Dimensions | |
Unit Weight | 58 lbs. |
Unit Size L x W x H | 15.35 X 11 X 7 inches |
Shipping Weight | 66 lbs. |
Shipping L x W x H | 20.5 X 13.8 X 12.2 inches |
AIMS Power 3000 Watt Inverter Charger - PICOGLF30W12V120V
Order shipment preparation takes 3 days. Once shipped orders usually take 2 weeks to be delivered. These are estimations; delivery can be delayed for reasons beyond our control. You can always contact us to know the exact delivery time once you placed an order with us. Have a look at our shipping policy here.
