SunStar Industrial 100K BTU/30ft Straight Tube Tough Guy Positive Pressure Heater/LP/Two Stage

SunStar Industrial 100K BTU/30ft Straight Tube Tough Guy Positive Pressure Heater/LP/Two Stage

Constructed with completely aluminized steel, this heater withstands high humidity and corrosive environments. Its push-through system ensures that combustion products are safely directed through the combustion chamber, enhancing safety and efficiency.

Customizable and Versatile Design

Choose from 8 different BTU sizes and over 60 configurations to customize your infrared heating system according to specific industrial needs. It supports both sidewall and through-the-roof venting options, providing flexibility in installation.

Quiet Operation and Low Maintenance

Equipped with a quiet blower motor (less than 60dB) housed in a burner box with heavy-duty permanently lubricated ball bearings, this heater operates smoothly and requires minimal maintenance. It features a 30-second pre-purge period before ignition and a diaphragm air switch for venting proof before gas flow and ignition.

Enhanced Safety Features

The SunStar Industrial Heater includes a heavy-duty cast iron burner, reliable direct spark ignition system, and 100% gas shut-off safety control for maximum safety during operation. It also features a diagnostic monitoring light system and is CSA design certified for industrial use.

Features

• Completely Aluminized Steel Construction for High Humidity and Corrosive Environments

• Push Through System - products of combustion are pushed through the combustion chamber

• 8 different Btu sizes and more than 60 different configurations to custom design your infrared heating system

• CSA design certified

• Sidewall or through the roof venting

• Vented or indirect vented operation

• Includes 36″ stainless steel gas connector

• No draft hoods - totally enclosed combustion chamber

• Blower motor (less than 60dB) totally enclosed in the burner box - heavy duty permanently lubricated ball bearing, totally enclosed motor for maintenance-free operation

• 30 second per-purge period before ignition

• Diaphragm air switch for proof of venting before gas flow and ignition

• Heavy duty cast iron burner

• Reliable direct spark ignition system and 100% Gas Shut-Off Safety Control

• Inside or outside air for combustion (Up to 25 ft. outside combustion air capability)

• Diagnostic Monitoring Light System

• 4” O. D. heat treated aluminized steel combustion chamber (10’ length)

• Aluminized steel radiant tubes

• Suitable for horizontal or angle mounting up to 45°

• Up to 25 feet sidewall vent capability

• Highly efficient aluminum reflectors

• Individual reflectors can be rotated up to 45° to direct heat where needed

• Liquid Propane

• 100,000 BTU

• 4" vent connection

• Not for use in residential applications

Specifications
